| NBS.RAT.NO：093239 |
| Applicability |
| Cutting Thickness：0.2mm-8mm |
| ．Cutting speed：MAX. 1M/sec |
| ．Precision：Size adjustment
0.01mm |
| ．Cutting Accuracy：±0.05 |
|
| specification |
CIM-450 |
| Glass size Minimum |
50*50 |
| Gutting Maximum |
Ø450 |
| Driver Motor |
3HP |
| Power Soorce |
220V / 380V |
| Consome comp .Ressor Air |
26 |
| Work Amp |
10A |
Work Space
|
1530*1100*1300 |
| Machine Net Weight |
800 |
| Work High |
920 |
| Work High |
-660 |
| Compressor Air |
5 |
| Options |
有移動輪 |
| Features： |
| Metal grinding table |
| Vaccum system (4 individual zone) |
| Automatic vaccum table and blow function |
| Twin cutting heads with three pressure controlled by plc. |
| 50 sets memory for each cutting head |
| Adjustable twin way cutting speed |
| Touch screen. |
| Notice of inputing wrong sizes. |
| Intermission in cotting. |
| Pressure, cutting deepness & capacity of oil are adjustable
even empty-handed. |
| Dffset of cutting head. |
| Easy operation for those not well-versed. |
| Cutting prupose |
 |
|
|
